Part Number | Data Sheet | Generation | Qualification | Blocking Voltage VDC | RDS(on) | Recommended VGS | Current Rating | Total Gate Charge | PD(TJ=25℃) | Package | Release Schedule | Recommended for New Design? |
---|---|---|---|---|---|---|---|---|---|---|---|---|
A3M015L120QANB | Gen 3B | Automotive | 1200 V | 15 mΩ | 18 V | 126 A | 222 nC | 484 W | TO247-4 | 2024Q4 | Yes | |
A3M020L120QNNB | Gen 3B | Industrial | 1200 V | 20 mΩ | 18 V | TBD | TBD | TBD | TO247-4 | 2024Q4 | Yes | |
A3M030L120QNNB | Gen 3B | Industrial | 1200 V | 30 mΩ | 18 V | TBD | TBD | TBD | TO247-4 | 2024Q4 | Yes | |
A3M040L120QNNB | Gen 3B | Industrial | 1200 V | 40 mΩ | 18 V | TBD | TBD | TBD | TO247-4 | 2024Q4 | Yes | |
A3M011L075HANB | Gen 3B | Automotive | 750 V | 11mΩ | 18 V | 145 A | 220 nC | 484 W | TO263-7 | 2024Q3 | Yes | |
A3M025L07QNNB | Gen 3B | Industrial | 750 V | 25 mΩ | 18 V | TBD | TBD | TBD | TO247-4 | 2024Q3 | Yes | |
A3M040L075QANB | Gen 3B | Automotive | 750 V | 40 mΩ | 18 V | TBD | TBD | TBD | TO247-4 | 2024Q3 | Yes | |
A3M055L075QANB | Gen 3B | Automotive | 750 V | 55 mΩ | 18 V | 37 A | 57 nC | 136 W | TO247-4 | 2024Q3 | Yes | |
A3M014F120QNN | Gen 3A | Industrial | 1200 V | 14mΩ | 15 V | 135 A | 277 nC | 682 W | TO247-4 | Available | Yes | |
A3M030F120QNN | Gen 3A | Industrial | 1200 V | 30 mΩ | 15 V | 69 A | 134 nC | 278 W | TO247-4 | Available | Yes | |
A3M040F120QNN | Gen 3A | Industrial | 1200 V | 40 mΩ | 15 V | 50 A | 99 nC | 230 W | TO247-4 | Available | Yes | |
A3M080F120QNN | Gen 3A | Industrial | 1200 V | 80 mΩ | 15 V | 29 A | 51 nC | 160 W | TO247-4 | Available | Yes | |
ACM018P120QNN | Gen 2+ | Industrial | 1200 V | 18 mΩ | 20 V | 105 A | 230 nC | 428 W | TO247-4 | Available | Yes | |
ACM035P120QNN | Gen 2+ | Industrial | 1200 V | 35 mΩ | 20 V | 69 A | 136 nC | 300 W | TO247-4 | Available | Yes | |
ACM035P120QSN | Gen 2+ | Solar | 1200 V | 35 mΩ | 20 V | 69 A | 136 nC | 300 W | TO247-4 | Available | Yes | |
ACM070P120QNN | Gen 2+ | Industrial | 1200 V | 70 mΩ | 20 V | 39 A | 72 nC | 200 W | TO247-4 | Available | Yes | |
ACM035P120QAN | Gen 2+ | Automotive | 1200 V | 35 mΩ | 20 V | 69 A | 136 nC | 330 W | TO247-4 | Available | Yes | |
ACM070P120QAN | Gen 2+ | Automotive | 1200 V | 70 mΩ | 20 V | 39 A | 72 nC | 200 W | TO247-4 | Available | Yes | |
ACM160P120QAN | Gen 2+ | Automotive | 1200 V | 160 mΩ | 20 V | 19 A | 32 nC | 120 W | TO247-4 | Available | Yes | |
ACM035P120BNN | Gen 2+ | Industrial | 1200 V | 35 mΩ | 20 V | 69 A | 136 nC | 300 W | TO247-3 | Available | Yes | |
ACM070P120BNN | Gen 2+ | Industrial | 1200 V | 70 mΩ | 20 V | 39 A | 72 nC | 200 W | TO247-3 | Available | Yes | |
ACM160P120BNN | Gen 2+ | Industrial | 1200 V | 160 mΩ | 20 V | 19 A | 32 nC | 120 W | TO247-3 | Available | Yes | |
ACM035P120HAN | Gen 2+ | Automotive | 1200 V | 35 mΩ | 20 V | 69 A | 136 nC | 300 W | TO263-7 | Available | Yes | |
ACM070P120HAN | Gen 2+ | Automotive | 1200 V | 70 mΩ | 20 V | 39 A | 72 nC | 200 W | TO263-7 | Available | Yes | |
ACM160P120HANB | Gen 2+ | Automotive | 1200 V | 160 mΩ | 20 V | 19 A | 32 nC | 120 W | TO263-7 | Available | Yes | |
ACM030F065QANC | Gen 2++ | Automotive | 650 V | 30 mΩ | 15 V | 70 A | 111 nC | 246 W | TO247-4 | Available | Yes | |
ACM045F065QANC | Gen 2++ | Automotive | 650 V | 45 mΩ | 15 V | 51 A | 79 nC | 200 W | TO247-4 | Available | Yes | |
ACM060F065QANC | Gen 2++ | Automotive | 650 V | 60 mΩ | 15 V | 42 A | 59 nC | 176 W | TO247-4 | Available | Yes | |
ACM030F065QNNC | Gen 2++ | Industrial | 650 V | 30 mΩ | 15 V | 70 A | 111 nC | 246 W | TO247-4 | Available | Yes | |
ACM045F065QNNC | Gen 2++ | Industrial | 650 V | 45 mΩ | 15 V | 51 A | 79 nC | 200 W | TO247-4 | Available | Yes | |
ACM060F065QNNC | Gen 2++ | Industrial | 650 V | 60 mΩ | 15 V | 42 A | 176 nC | 59 W | TO247-4 | Available | Yes | |
ACM030F065LNNC | Gen 2++ | Industrial | 650 V | 30 mΩ | 15 V | TBD | TBD | TBD | TOLL | Available | Yes | |
ACM045F065LNNC | Gen 2++ | Industrial | 650 V | 45 mΩ | 15 V | TBD | TBD | TBD | TOLL | Available | Yes | |
ACM060F065LNNC | Gen 2++ | Industrial | 650 V | 60 mΩ | 15 V | TBD | TBD | TBD | TOLL | Available | Yes | |
ACM030F065BNNC | Gen 2++ | Industrial | 650 V | 30 mΩ | 15 V | 70 A | 111 nC | 246 W | TO247-3 | Available | Yes | |
ACM045F065BNNC | Gen 2++ | Industrial | 650 V | 45 mΩ | 15 V | 51 A | 79 nC | 200 W | TO247-3 | Available | Yes | |
ACM060F065BNNC | Gen 2++ | Industrial | 650 V | 60 mΩ | 15 V | 42 A | 176 nC | 59 W | TO247-3 | Available | Yes |
